Червячная лебёдка для эвакуаторов Come Up Wolf 12.0, 4.6 л/с
Номинальное тяговое усилие: 5443кг
Напряжение: 12v,24v
Передаточное число: 424:1
Диаметр и длина троса: 9,1мм х 30,5м
Габаритный размер: 561х366х264 мм
Подробное описание:
Robust, extreme heavy duty worm drive.
Heavy duty series wound motor for high torque output and fast line speed under extreme operating conditions.
Detachable weather-resistant control box mounted elsewhere on the vehicle.
2 stages spur gears plus 1 exceptionally strong worm gear for reversing protection.
Irreversible worm gear brake as well as an auxiliary mechanism ratchet wheel brake performs instant braking.
Mechanism lever clutch for rapid wire rope pay-out.
Heavy duty sealed contactor gives better water resistance and lower amp. draw.
Higher D/d ratio (drum dia. / rope dia.) allows light commercial applications of car transporter, wrecker, tractor, lorry and fire/rescue engine.
Meets SAE J706 CE Machinery Directive 98/37/EC.
Performance data: Line Pull and Rope Capacity
Layer of Wire Rope |
Line Pull
kg / lb |
Total Rope on the Drum
m / ft |
1st Layer |
5,443 / 12,000 |
7.3 / 24.0 |
2nd Layer |
4,563 / 10,060 |
16.0 / 52.6 |
3rd Layer |
3,928 / 8,659 |
26.1 / 85.8 |
4th Layer |
3,448 / 7,601 |
30.5 / 100 |
|
Performance data: Line Speed and Amp Draw (1st layer of wire rope on the drum)
Line Pull
kg / lb |
Line Speed
mpm / fpm |
Amp Draw
12 V |
Amp Draw
24 V |
No Load |
6.2 / 20.3 |
70 |
40 |
2,722 / 6,000 |
2.7 / 8.9 |
180 |
85 |
3,629 / 8,000 |
1.7 / 5.6 |
270 |
120 |
4,535 / 10,000 |
1.4 / 4.6 |
310 |
150 |
5,443 / 12,000 |
1.0 / 3.3 |
350 |
190 |
|
